Cross-Validation
Lecture 18
March 6, 2026
Regularization
Can reduce degrees of freedom with regularization (shrinkage of estimates (e.g. LASSO) vs. “raw” MLE) or dimensionality reduction (model simplification).
Source: Richard McElreath
Held Out Data
Instead, let’s divide our data into a training dataset \(y_k\) and testing dataset \(\tilde{y}_l\).
- Fit the model to \(y_k\);
- Evaluate error on \(\tilde{y}_l\).
Held Out Data
Training Data MSE: 19899.2
Testing Data MSE: 7498.4
Training Data Score: 19899.2
Testing Data Score: 7498.4
Consistency of C-V
Code
# create data set
Random.seed!(1)
ntrain = 20
x = rand(Uniform(-2, 2), ntrain)
f(x) = x.^3 .- 5x.^2 .+ 1
y = f(x) + rand(Normal(0, 2), length(x))
# function to fit polynomial model
function polyfit(d, x, y)
function m(d, θ, x)
mout = zeros(length(x), d + 1)
for j in eachindex(x)
for i = 0:d
mout[j, i + 1] = θ[i + 1] * x[j]^i
end
end
return sum(mout; dims=2)
end
θ₀ = [zeros(d+1); 1.0]
lb = [-10.0 .+ zeros(d+1); 0.01]
ub = [10.0 .+ zeros(d+1); 20.0]
optim_out = optimize(θ -> -sum(logpdf.(Normal.(m(d, θ[1:end-1], x), θ[end]), y)), lb, ub, θ₀)
θmin = optim_out.minimizer
mfit(x) = sum([θmin[i + 1] * x^i for i in 0:d])
return (mfit, θmin[end])
end
# create out-of-sample data for testing generalizability
ntest = 20
xtest = rand(Uniform(-2, 2), ntest)
ytest = f(xtest) + rand(Normal(0, 2), length(xtest))
# calculate cross-validation fits and scores
function cv_poly(d, x, y, nfolds=5)
# split data into folds
labels = repeat(1:nfolds, outer=Int(length(x) / nfolds))
fold_labels = shuffle(labels) # randomly permute the labels
# do C-V
cv_error = zeros(nfolds)
for fold in 1:nfolds
test_idx = findall(fold_labels .== fold)
train_idx = setdiff(1:length(x), test_idx)
m, σ = polyfit(d, x[train_idx], y[train_idx])
cv_error[fold] = mean((m.(x[test_idx]) .- y[test_idx]).^2)
end
return cv_error
end
in_error = zeros(11)
out_error = zeros(11)
cv_error = zeros(11)
nfold = 4
#calculate sum of squared errors
for d = 0:10
m, σ = polyfit(d, x, y)
in_error[d+1] = mean((m.(x) .- y).^2)
out_error[d+1] = mean((m.(xtest) .- ytest).^2)
cv_error[d+1] = mean(cv_poly(d, x, y, nfold))
end
plot(0:10, in_error, marker=(:circle, :blue, 8), line=(:blue, 3), label="In-Sample Error", xlabel="Polynomial Degree", ylabel="Mean Squared Error", legend=:top)
plot!(0:10, out_error, marker=(:circle, :red, 8), line=(:red, 3), label="Out-of-Sample Error")
plot!(0:10, cv_error, marker=(:circle, :purple, 8), line=(:purple, 3), label="C-V Error")
plot!(yaxis=:log)
plot!(xticks=0:1:10)
plot!(size=(900, 450))
Figure 3: Impact of increasing model complexity on model fits
LOO-CV Example
Model: \[D \rightarrow S \ {\color{purple}\leftarrow U}\] \[S = f(D, U)\]
LOO-CV Flow
- Drop one value \(y_i\).
- Refit model on \(y_{-i}\).
- Predict \(p(\hat{y}_i | y_{-i})\).
- Evaluate \(-\log p(y_i | y_{-i})\).
- Repeat on rest of data set.
LOO-CV Flow
- Drop one value \(y_i\).
- Refit model on \(y_{-i}\).
- Predict \(p(\hat{y}_i | y_{-i})\).
- Evaluate \(-\log p(y_i | y_{-i})\).
- Repeat on rest of data set.
Challenges with C-V With Structured Data
- Data structure creates dependencies: holding out a random subset of data might not align properly.
- Example: What if we randomly hold out data in the middle of a time series?
Code
μ = 0.01
ρ = 0.7
σ = 0.5
ar_var = sqrt(σ^2 / (1 - ρ^2))
T = 100
ts_stat = zeros(T)
for i = 1:T
if i == 1
ts_stat[i] = rand(Normal(0, ar_var))
else
ts_stat[i] = ρ * ts_stat[i-1] + rand(Normal(0, σ))
end
end
p = plot(1:T, ts_stat, marker=:circle, markersize=8, color=:blue, label="Training Data", xlabel="Time", linewidth=3, size=(600, 500))
p1 = deepcopy(p)
test_idx1 = sample(1:nrow(tds), 5, replace=false)
scatter!(p1, test_idx1, ts_stat[test_idx1], color=:red, markersize=8, label="Testing Data")
LFO-CV Example
- Set minimum length \(m\).
- Refit model on \(\{y_1, y_m\}\).
- Predict \(p(\hat{y}_{m+1} | y_{1:m})\).
- Evaluate \(-\log p(y_{m+1} | y_{1:m})\)
- Increment \(m\) by 1 and repeat until end is hit.
- Take mean of individual scores.
Code
function cv_lfo(dat, m)
ts_pred = zeros(length(dat) - m, 10_000)
log_p = zeros(length(dat) - m)
function ar1_loglik_whitened(θ, dat)
# might need to include mean or trend parameters as well
# subtract trend from data to make this mean-zero in this case
α, ρ, σ = θ
T = length(dat)
ll = 0 # initialize log-likelihood counter
for i = 1:T
if i == 1
ll += logpdf(Normal(α / (1 - ρ), sqrt(σ^2 / (1 - ρ^2))), dat[i])
else
r = dat[i] - (α + ρ * dat[i-1])
ll += logpdf(Normal(0, σ), r)
end
end
return ll
end
lb = [-5.0, -0.99, 0.01]
ub = [5.0, 0.99, 5]
init = [0.0, 0.6, 0.3]
for i = (m+1):T
optim_whitened = Optim.optimize(θ -> -ar1_loglik_whitened(θ, dat[1:(i-1)]), lb, ub, init)
θ = optim_whitened.minimizer
# get log score of data
log_p[i - m] = -logpdf(Normal(θ[1] .+ θ[2] * dat[i-1], θ[3]), dat[i])
# simulate predictions
ts_pred[i - m, :] = θ[1] .+ θ[2] * dat[i-1] .+ rand(Normal(0, θ[3]), 10_000)
end
return (log_p, ts_pred)
end
m = 10
log_p, ts_lfo = cv_lfo(ts_stat, m)
p = plot(1:m, ts_stat[1:m], marker=:circle, markersize=8, color=:blue, label="Training Data", xlabel="Time", linewidth=3, size=(600, 500))
pred_quantile = quantile(ts_lfo[1, :], [0.05, 0.95])
scatter!(p, [m+1], [ts_stat[m+1]], yerr = pred_quantile .+ ts_stat[m+1], marker=:circle, markersize=8, color=:red, label="Testing Data")
LFO-CV Example
- Set minimum length \(m\).
- Refit model on \(\{y_1, y_m\}\).
- Predict \(p(\hat{y}_{m+1} | y_{1:m})\).
- Evaluate \(-\log p(y_{m+1} | y_{1:m})\)
- Increment \(m\) by 1 and repeat until end is hit.
- Take mean of individual scores.
Code
i = m + 1
p = plot(1:i, ts_stat[1:i], marker=:circle, markersize=8, color=:blue, label="Training Data", xlabel="Time", linewidth=3, size=(600, 500))
pred_quantile = quantile(ts_lfo[i - m + 1, :], [0.05, 0.95])
scatter!(p, [i+1], [ts_stat[i+1]], yerr = pred_quantile .+ ts_stat[i+1], marker=:circle, markersize=8, color=:red, label="Testing Data")
